Analog Domain Audio M75D. Integrated Amplifier.

Product not available.

Colour


bloques info producto

Bank Transfer (3% OFF)

If you make the payment via bank transfer, you will receive an extra 3% discount on your order.

Individual Consultancy

Contact us without any obligation.

957460112
info@audiohum.com

Need to upgrade your equipment?

Would you be interested in trading in a device when purchasing this item?

Renovar equipo




The M75 range of dual channel amplifiers from Analog domain represents the current state of the art in linear amplification technology. It is the result of 15+ years experience in high-performance amplifier circuit design, created to deliver exceptional performance at an attractive price point.

The M75 features our recently disclosed proprietary Excalibur circuit. Near-zero distortion, a noise floor well below the human perceptual threshold and the generous power output capability of the Excalibur give the M75 its ability to amplify signals with extreme resolution and control, raising the enjoyment of music to an unprecedented level.

The M75  is available in three configurations: two integrated amplifiers and a matching 2-channel power amplifier, for installations requiring more power in stereo, or for building multi-way systems with frequency splitting, or multi-channel systems:

M75D – Stereo integrated amplifier, stepped analogue volume attenuator, remote control

TECHNICAL SPECIFICATIONS

Type: Solid-state, 2-channel integrated amplifier with headphone amplifier

Analogue inputs: Two single-ended line-level inputs (via RCA jacks), two balanced inputs (via XLR connectors)

Digital inputs: N/A

Analogue outputs: One pre-power loop (via 5 pin DIN)

Input impedance (high-level): 20kOhms balanced, 10kOhms on RCA
Input impedance (power amp): 10kOhms [differential]

Output impedance (preamp): 10 Ohms

Headphone Loads: Any!

Power Output: 400Wpc @ 4 Ohms, 250Wpc @ 8 Ohms

Bandwidth: 2 Ohm, THD < 0.1% 5Hz – 50kHz

Distortion (THD+N):  20kHz BW, 8 Ohm nom. power < 0.002%

Signal to Noise Ratio: >120dB referenced to full power

Dimensions (H×W×D) inc. feet: 135 × 440 × 440mm

Weight: 25kg
