Specifications
Model: K3s
Weight: 0.82g
Max. Sampling rate:
384kHz-32bit/DSD256
192kHz-32bit/DSD64 (coaxial)
96kHz-32bit (optical)
Hardware: XMOS: XU208, DAC: ES9038Q2M, LPF: TI OPA1612, AMP: OPA926×2
Volume control: ADC
Sampling rate indicator: supported
Firmware update: XMOS edition update via USB
Recommended impedance: 16~150 Ω
Balanced output: 2.5mm
USB: Type C (USB 1.0/USB 2.0)
Analogue output port (LO): standard 3.5mm
Headphone port: 3.5mm standard
Power supply: DC5V 500mA (recommended)
THD + N: ＜0.0012% (1kHz/10kΩ/A-weighted)
Channel separation: ≥94dB (1kHz/10kΩ)
Frequency response: 20Hz~20kHz (-3dB)
SNR: ≥121dB (A-weighted)
Noise Floor: ＜1.8μV (A-weighted)
LO output level: 2.0Vrms (1kHz/10kΩ)
Specifications 3.5mm output
Output power 1: ≥220mW (16Ω/THD+N＜1%, USB DAC)
Output power 2: ≥120mW (32Ω/THD+N＜1%, USB DAC)
Output power 3: ≥13mW (300Ω/THD+N＜1%, USB DAC)
THD+N: 0.0012% (1 kHz/32Ω/A-weighted)
Noise floor:＜2μV (A-weighted) SNR ≥121dB (A-weighted)
Frequency response: 20Hz~20kHz (-3dB)
Peak output voltage:＞5.6Vp-p
Output impedance:＜1.0Ω (32Ω)
SNR: ≥119dB (A-weighted
Channel separation: ≥80dB (1 kHz/32Ω, USB DAC)
Specifications 2.5mm output
Output power 1: ≥344mW (16Ω/THD+N＜1%, USB DAC)
Output power 2: ≥120mW (32Ω/THD+N＜1%, USB DAC)
Output power 3: ≥13mW (300Ω/THD+N＜1%, USB DAC)
THD+N: 0.0012% (1 kHz/32Ω/A-weighted)
Noise floor:＜2μV (A-weighted) SNR ≥121dB (A-weighted)
Frequency response: 20Hz~20kHz (-3dB)
Peak output voltage:＞5.6Vp-p
Output impedance:＜1.0Ω (32Ω)
SNR: ≥119dB (A-weighted
Channel separation: ≥80dB (1 kHz/32Ω, USB DAC)
