The Phono Box DS2 USB is defined as "phono preamplifier with USB digital output compatible with high resolution audio". A truly unique accomplishment that agglutinates the know-how of Pro-Ject Audio Systems to make the growing number of fans who are incorporating the vinyl record to their music collection from the comments through their favorite digital friends. This means that inside the Phono DS2 USB box there is an audiophile level phono circuitry - adjustable to perfectly match any pickup capsule - and, at the same time, an A / D conversion section to convert into Digital signal from our turntable, so that we can listen through a portable audio player, a personal computer or a "smartphone". As it corresponds to a model belonging to the range DS of Box Design, the Phono Box DS2 USB has been executed with eminently purist criteria. Thus, the monophonic dual architecture phono section and compatible with both mobile (MM) and mobile coil (MC) capsules, includes a RIAA equalization circuitry blade, as well as the possibility of selecting both the impedance and the capacitance of Input For the A / D conversion section, you can convert any analog signal (not just the procedure of a turntable also from another analog source) into digital to PCM resolution with sampling at 192 kHz or DSD at 5 '6 MHz , Although in the latter case via USB.
Technical characteristics
Earphone with built-in A / D conversion of very high performance.
Audiophile phono preamplifier compatible with MM and MC capsules.
Monophonic double circuit topology.
High precision RIAA equalization.
Subsonic filter (-12 dB at 20 Hz).
5 gain settings, 2 input impedance and 3 input capacitance.
A / D conversion to PCM resolution at 192 kHz or DSD128 (via USB only).
Analog line input and output.
USB digital output and EIAJ-TosLink optics.
All metal construction with design without screws.
Signal to noise ratio of 94 dB with MM capsules and 75 dB with MC capsules.
Dimensions: 206x70x200 mm (W x H x D).
Weight: 1.5 kg (without power supply).
Colors: Black and white. Optional wooden side panels.
