ETON 11-612/C8/50
ETON 11-612/C8/50 RP Bass-mid Woofer
bloques info producto
Bank Transfer (3% OFF)
If you make the payment via bank transfer, you will receive an extra 3% discount on your order.
Need to upgrade your equipment?
Would you be interested in trading in a device when purchasing this item?
Classic 11'' bass-/midrange speaker for 3-way systems, serrated paper membrane geometry, very precise bass reprodruction also in deep frequencies, agile sound.
Highlights:
Uncompromising sound quality
Uncolored sound reproduction
Frequency range: 30 – 1000 Hz
Product details:
ETON 11-612/C8/50 RP Bass-mid Woofer
Our Orchestra Series with traditional paper cone, newly interpreted with ETON’s expertise. The special, radial ribbing and long-fiber, highly absorbing paper mixture creates a very high degree of impulse
fidelity and precision, even at extremely high levels; not to mention the resulting individualized appearance. The special paper mixture guarantees homogeneity by preventing mode formations at all possible frequency ranges.
The Orchestra mid range drivers and woofers are characterized by their natural, warm sound. This results in a balanced, well-contoured and soft mid range. In the low frequency range, our Orchestra is more than convincing with its voluminous and impulsive bass response.
With its multiply ventilated and flow-supporting cast basket, the ferrite drive ensures that any occurring compression effects are reduced to a minimum.
Specifications:
Woofer Series: Orchestra
Woofer Type: Bass-mid Woofer
Nominal Diameter: 11"
Power Handling (RMS): 120 Watts
Impedance (Z): 8 Ω
Sensitivity (SPL at 1m / 2.83V): 91 dB
DC Resistance (Re): 5.3 Ω
Voice Coil Inductance (Le): 1.03 mH
Resonant Frequency (Fs): 23 Hz
Mechanical Q (Qms): 7.87
Electromagnetic Q (Qes): 0.30
Total Q (Qts): 0.29
Moving Mass Of Diaphragm (Mmd): 54 g
Mechanical Compliance of Suspension (Cms): 0.81 mm/N
Surface Area of Cone (Sd): 366 cm2
BL Product (BL): 11.4 Tm
Compliance Equivalent Volume (Vas): 152 dm3
Maximum Linear Excursion (Xmax): 5 mm
Driver's Mechanical Losses (Rms): 1.13 kg/s
Voice Coil Former: Kapton
Magnet Material: Ferrite
Overall Outside Diameter: 280 mm
Overall Depth: 110.5 mm
Baffle Cutout Diameter: 242 mm
Mounting Hole Diameter: 5.5/9.7 mm
