MOREL CAT 298 Soft dome tweeter
Morel CAT 298 28mm soft dome tweeter
Bankwire payment (3% DTO)
If you choose Bankwire payment you will get a 3% discount on your order.
Shipping Policy
Return policy
An updated and more cost effective version of the famous MDT-29 and MDT-33, the CAT298 also features a treated 1-1/8" soft dome, ferrofluid cooling, and aluminum voice coil.
Highlights:
104 mm aluminum faceplate
Large diameter voice coil
Replaceable dome/coil assembly
Ferrofluid cooled
High power handling
Sturdy gold plated input tags
Product details:
Morel Classic Advanced CAT 298 1" Dome Tweeter
An updated and more cost effective version of the famous MDT-29 and MDT-33, the CAT298 also features a treated 1-1/8" soft dome, ferrofluid cooling, and aluminum voice coil, but without the double magnet system and damped rear chamber. Very smooth on-and off-axis frequency response.Cúpula textil Morel de 28mm
Morel 1" textile dome tweeter
Ferrofluid cooled
Replaceable voice coil
Aluminum face-plate
Hand treated dome
Gold-plated terminals
Flange 104mm (3.7")
Cut-out 75mm (2.83")
Depth 27mm (1.06")
Resisetence Znom 8 ohm
Resonance Re 5.2 ohm
Coil inductance Le@1kHz 0.05 mH
Frecuance fs 900 Hz
Qms -
Qes -
Qts -
Movingl mass Mms 0.5 g
Cms - mm/N
Effective Piston Area Sd 6.0 cm2
BLProduct 3.3 N/A
Vas - ltrs
Xmax - mm peak
VC Ø 28 mm
Sensitivity
1W / 1m 89 dB
Nom. Power DIN 80 W
Net weight 0.54 kg
