MOREL CAT 328-104 Tweeter is a 104mm faceplate diameter soft dome tweeter, with a 28mm Hexatech replaceable Aluminium voice coil. It features Morels’ IDR™ Improved Dispersion Recess aluminum face plate, ferrofluid cooling and high power handling.
Highlights:
104mm IDR™ Improved Dispersion Recess aluminum face plate
Large Hexatech™ Aluminum voice coil
Replaceable Acuflex™ dome / coil assembly
Ferro fluid cooled
High power handling
Sturdy gold plated input tabs
Product details:
Morel Classic Advanced CAT 328-104 1" Dome Tweeter
The MOREL CAT 328-104 Tweeter is a new 104mm faceplate diameter soft dome tweeter replacing and upgrading the MDT-32S, with a 28mm Hexatech replaceable Aluminium voice coil. It features Morels’ IDR™ Improved Dispersion Recess aluminum face plate, ferrofluid cooling and high power handling. Priced individually, supplied in pairs.
Morel 1" textile dome tweeter
Hand coated dome Ferrofluid cooled
Replaceable voice coils
Aluminum face-plate
Gold-plated terminals
Rear chamber
Flange 104mm (3.7")
Cut-out Ø 75mm (2.87")
Depth 43mm (1.69")
Resistence Znom 8 ohm
Resonance Re 5.2 ohm
Coil inductance Le@1kHz 0.09 mH
Frecuance fs 650 Hz
Moving mass Mms 0.44 g
Effective Piston Area Sd 6.0 cm2
BL Product 3.5 N/A
VC Ø 28 mm
Sensitivity 1W / 1m 90 dB
Nom. Power DIN 200 W
Net weight 0.56 kg
