MOREL Supreme SCW 636 6" Woofer
Morel Supreme SCW 636 6" Woofer
€464.00
Have you seen it cheaper? Contact us
Delivery time 10 days
Bankwire payment (3% DTO)
If you choose Bankwire payment you will get a 3% discount on your order.
Shipping Policy
Return policy
The Morel Supreme Series SCW636 woofer features a 16 mm long, 3" diameter Hexatech voice coil that provides plenty of deep bass punch, and a copper-covered pole piece design reduces inductance.
Highlights:
Carbon fiber/Rohacell/carbon fiber composite sandwich cone
3" Hexatech™ aluminum voice coil
Copper pole piece sleeve reduces inductance
Hybrid™ neodymium/ferrite magnet
Uniflow™ aluminum diecast chassis
High power handling
Product details:
Morel Supreme SCW 636 6" Woofer
The Morel Supreme Series SCW636 woofer features a 16 mm long, 3" diameter Hexatech voice coil that provides plenty of deep bass punch, and a copper-covered pole piece design reduces inductance. Morel's Uniflow open frame virtually eliminates diaphragm back pressure and excursion noise.
Product Specifications
- Nominal Diameter 6"
- Power Handling (RMS)150 Watts
- Power Handling (max)1000 Watts
- Impedance 6 ohms
- Frequency Response30 to 5,000 Hz
- Sensitivity87 dB 2.83V/1m
- Voice Coil Diameter 3"
Thiele-Small Parameters
- Resonant Frequency (Fs)40 Hz
- DC Resistance (Re)4.5 ohms
- Voice Coil Inductance (Le)0.29 mH
- Mechanical Q (Qms)1.76
- Electromagnetic Q (Qes)0.35
- Total Q (Qts)0.29
- Compliance Equivalent Volume (Vas)0.65 ft.³
- Mechanical Compliance of Suspension (Cms)0.97 mm/N
- BL Product (BL)7.2 Tm
- Diaphragm Mass Inc. Airload (Mms)16g
- Maximum Linear Excursion (Xmax)5 mm
- Surface Area of Cone (Sd)119 cm²
Materials of Construction
- Cone MaterialCarbon Fiber Composite
- Voice Coil Wire MaterialAluminum
- Voice Coil FormerAluminum
- Basket / Frame MaterialCast Aluminum
- Magnet MaterialNeodymium
Mounting Information
- Overall Outside Diameter 6.3"
- Baffle Cutout Diameter 5.512"
- Depth 2.72"
- Mounting Holes6
Optimum Cabinet Size (determined using BassBox 6 Pro High Fidelity suggestion)
- Sealed Volume 0.08 ft.³
- Sealed F3118 Hz
- Vented Volume 0.18 ft.³
- Vented F375 Hz
Morel Supreme SCW 636 6" Woofer
- Brand Morel
- Model Supreme SCW 636
- Part Number 297-114
- Unit of Measure EA
- Weight 3.1 lbs-1.4Kg
