ORTOFON MC X20
MC moving coil cartridge with elliptical stylus and pure silver coils.
Delivers natural, detailed, and dynamic sound. Robust stainless steel construction and optimized design for maximum precision.
Output: 0.4 mV
Compliance: 13 μm/mN
Weight: 8.6 g
Stylus: Elliptical
Response: 20 Hz – 20 kHz
bloques info producto
Bank Transfer (3% OFF)
If you make the payment via bank transfer, you will receive an extra 3% discount on your order.
Need to upgrade your equipment?
Would you be interested in trading in a device when purchasing this item?
Ortofon MC X20. High-End Moving Coil Cartridge for Pure Analog Emotion
Rediscover the magic of vinyl with the Ortofon MC X20, a high-performance moving coil (MC) cartridge designed to deliver immersive, emotional, and ultra-detailed playback. Featuring a nude elliptical diamond stylus, the MC X20 captures every nuance of your music with breathtaking clarity and natural musicality.
Deep, Detailed & Emotionally Engaging Sound
Engineered for demanding audiophiles, the MC X20 offers a wide, open soundstage with enhanced channel separation and precise tonal balance. Its linear frequency response and exceptional tracking ability allow every note to emerge with texture, depth, and realism—bringing your favorite recordings to life like never before.
Advanced MC Technology for Audiophile Listening
Nude Elliptical Stylus: Offers superior groove contact and improved tracking accuracy, reducing distortion and enhancing detail.
Aluminum Cantilever: Combines lightweight construction and rigidity for optimal signal transmission and control.
Quad Coil Design with Pure Silver Wire: Ensures crystal-clear signal integrity, reduced coloration, and maximum microdetail.
Precision Engineering Meets Analog Soul
Built around a rigid, optimized body and Ortofon’s custom-developed suspension system, the MC X20 delivers exceptional stability and performance. With a low internal impedance of just 6 ohms, it ensures seamless integration with a wide range of MC phono preamps—providing an effortless path to high-fidelity analog sound.
Key Specifications
Type: Moving Coil (MC)
Stylus: Nude Elliptical (r/R 8/18 μm)
Cantilever: Aluminum
Frequency Response: 20 Hz – 20 kHz (±1 dB)
Channel Separation @ 1 kHz: 25 dB
Channel Balance @ 1 kHz: 0.5 dB
Output Voltage: 0.4 mV (1 kHz, 5 cm/s)
Dynamic Compliance, Lateral: 15 µm/mN
Tracking Force: Recommended 2.0 g
Internal Impedance: 6 Ohms
Coil Material: High-Purity Silver
Recommended Load Impedance: >50 Ohms
Cartridge Weight: 8.6 g
Ortofon MC X20 is the perfect choice for vinyl lovers seeking a refined, analog listening experience—rich in dynamics, nuance, and tonal purity. Whether you're building a high-end system or upgrading your cartridge, the MC X20 offers uncompromising performance with a distinctly musical soul.
