The original Aquarius was one of the most cost effective power cleaning upgrades you could buy. The new V5 model takes the Aquarius concept to a higher level. There is more instantaneous power on tap due to a 35% increase in circuit board copper loading, direct current resistance has been improved by at least 25% approaching the ideal of zero ohms. The protection has also been raised to 81,000 instantaneous A. This six-way network cleaning unit complies with the market standard. It has two high current outlets for amplifiers, subwoofers, etc., and four medium current outlets for other components. Each Aquarius outlet has its own dedicated net cleaner net, so there are six net cleaners in one box.

Features:

Suitable for all audio or AV systems.

RFI reduction 60dB.

6 power cleaning circuits optimized to effectively eliminate mains noise in common and differential mode.

4 independent outputs for the source components (6A.)

2 independent high current outputs for power amplifiers, active subwoofers, active loudspeakers, etc. (16A).

Easy replacement thermomagnetic fuse system.

Instantaneous protection of 81,000A, continuous of 40,000A.

Fully grounded star network.

Silver-plated Ohno Continuous Cast copper internal wiring with FEP virtual air dielectric.

SYSTEM LINK socket to expand outputs and maintain a fixed ground reference.

Supplied with the IsoTek EVO3 PREMIER power cable.

Departures available for the United Kingdom, the European Union, the United States, Australia and Switzerland.

IsoTek's iconic Aquarius power cleaning system has been dramatically improved and boldly redesigned. Not only is the V5 avant-garde in its visual design, appearing to be carved from a single block of aluminium, it harnesses the latest technical innovations from a leading brand in the specialized field of AV and audio power systems.

The V5 Aquarius is an innovative cleaning and power distribution system measuring 450mm wide, 350mm deep and 110mm high. It has 6 independent outlets, each with its own power cleaning network. Therefore, Aquarius is six energy cleansing grids in one box. Differential and common mode noise is drastically reduced. Cross contamination from connected components is also kept to a minimum due to multiple power cleaning stages for each outlet. Most power filters tie the output taps together, each running in series. This is a mistake, as differential mode noise created by connected electronics will cross-contaminate from one output jack to the next.

The electrical architecture and design of the V5 Aquarius have been drastically improved. The PCB layout and topology have been revised, offering over 35% improved amperage and lower resistance. Unique critical components (custom made) have better overall tolerances with improved inductance and current handling. The new circuit offers twice the inductance, with a 40% increase in current leading to more open sound staging, micro dynamics and detail with more immediate timing. Throughout the design the direct current withstand (DCR) has been dramatically improved. As part of IsoTek's goal to reduce DCR to bring performance closer to the ideal of zero ohms,

These technological improvements make the V5 Aquarius offer absolute power, an unrestricted current delivery within what the electric company can supply and the regulations allow.

The V5 is designed with two thermomagnetic fuses, one 16 A for the two high current output sockets, supplying 3680 W at 230 V or 1840 W at 115 V. The second 6 A for the four remaining medium current output sockets, supplying 1,380 W at 230 V or 690 W at 115 V, is dedicated to the source components and features IsoTek's exclusive Adaptive Gating © technology. This technology automatically detects the connected load and provides the ideal clean power based on energy consumption.

The thermomagnetic system is a substantial improvement over a standard ordinary fuse due to the contact surface. By virtue of its electrical function, a standard fuse must have a very fine wire, which is also the case with the expensive gold-plated audiophile versions. IsoTek's thermomagnetic fuse system offers at least 1,000 times better contact area, and a connection that is consistently strong.

The KERP © system (Kirchhoff's Equal Resistance Path) guarantees the same resistance and the same power supply to all outputs. Internal wiring is of the highest standard: ultra-pure, silver-plated Ohno Continuous Cast copper solid core conductor strands offer low resistance and high amperage. A fluorinated ethylene propylene (FEP) helix is ​​wrapped around the conductor before an extruded FEP dielectric protects the conductor and creates a virtual dielectric of air (VDA). This construction offers unmatched performance and provides the ultimate in high performance, low resistance internal power supply systems. In addition, an instant protection of 81 is provided.

The internal wiring of IsoTek products is synergized with the IsoTek range of power cables. A critical but overlooked area is maintaining consistency of design and material properties throughout an audio harness, whether it be signal carrying cables or its power cable network.

The V5 Aquarius also contains a System Link outlet, designed to link multiple units together while maintaining a fixed ground reference, and preserving the need for multiple outlets.

The V5 Aquarius has a high-quality yet highly functional design and is an excellent upgrade to a complete audio system. Also included is IsoTek's award winning Premier Power Cord.

SPECIFICATIONS:

NUMBER OF OUTLETS 6.

TYPE OF OUTLETS UK, EU, US, AU & CH.

MAINS INPUT 16A IEC C20.

MAINS VOLTAGE 100-240V / 50-60Hz.

MEDIUM CURRENT - 230V x4 (6A 1,380W in total).

MEDIUM CURRENT - 115V x4 (6A 690W total).

HIGH CURRENT - 230V x2 (16A 3,680W in total).

HIGH CURRENT - 115V x2 (16A 1,840W in total).

SYSTEM LINK x1.

PROTECTION AGAINST OVERVOLTAGES 81,000A.

DIMENSIONS (width x height x depth) 450 x 110 x 350mm.

WEIGHT 9.5kg.
