JMF AUDIO HQS 9001
JMF AUDIO HQS 9001
Stereo, 2x 250WRMS/8Ω 450WRMS/4Ω 550WRMS/2Ω (1Ω limit), 2x 80A. CMMR 100dB. Dimensions: 482 W x 149 H x 539 D (mm), 34Kg. Power cable PC3.
bloques info producto
Bank Transfer (3% OFF)
If you make the payment via bank transfer, you will receive an extra 3% discount on your order.
Need to upgrade your equipment?
Would you be interested in trading in a device when purchasing this item?
The HQS 9001 is JMF Audio's remarkable reference mono power amplifier, reproducing music with unrivalled density, articulation, subtlety and tonal accuracy, revealing the finest nuances. The Orose® machined aluminium enclosure houses an internal chassis and its sub-chassis.
Technical specifications:
- Impedance: 20kΩ
- Sensitivity: All models have the same voltage gain (facilitating multi-amplification).
- Connection: 3-pin XLR: metal housing, gold-plated contacts
- Common mode rejection: 100dB CMRR typ. based on psychoacoustic criteria as of 2012
- Type: High-precision balanced input stage (impedance matched to PRS1.5).
- Monitoring: Level metering (-15dB to +3dB), Input offset, Overload, High temp.
Output:
- RMS output power: 600W / 8Ω 1000W / 4Ω 1700W / 2Ω 3000W / 1Ω
- Output current capacity: 330A
- Operating load limit: 1 Ω (0.6 Ω): intentionally limited current for amplifier and loudspeaker protection
- Connection: JMF Audio LSS dia. 6 mm (120 A nominal continuous)
Noise and hum floor: Better than -125dB unweighted 1kHz (measured date 2012)
Wideband: 3Hz..100kHz (-3dB) 3Hz..40kHz (0dB) (intentionally limited for RF immunity)
Audio signal coupling: DC coupled (exclusive DC servo circuitry).
Protection circuitry:
Front panel standby control (prior to F version).
Automatic high-frequency high-signal protection
Automatic DC protection below 3 Hz
Automatic overheating protection
Automatic overload and short-circuit protection
Mains voltage monitoring - advanced protection (activation of protections reported on the front panel)
Power supply: 100, 120, 230-240 V AC (internal selection)
Automatic airflow
Sealed case design (no air passage inside the amplifier, no dust).
Case: Orose® machined anodised aluminium outer case up to 16 mm thick, machined steel and rose gold buttons
Dimensions (G version)
19"+ wide | 482 W (front panel) x 605 D x 186 H mm including airflow unit (not shown in the picture)
54 kg/unit
Net weight (G version)
Finishes: Silver or Black (anodised)
